Pepperl+Fuchs Tab-IND 10 Rugged ThinManager Ready Tablet, 10.1″, Wi-Fi, 128GB
For ThinManager-based digital workflows at the point of operation where a 10.1-inch tablet and Wi-Fi connectivity are required.
Key highlights
- ThinManager Ready: Intel N100 platform with 8 GB LPDDR5 RAM and 128 GB UFS storage
- 10.1-inch WUXGA display: 660 cd/m² with glove and wet-use support
- IP65 protection: 1 m concrete and 1.22 m plywood drop resistance
- Wi-Fi 6 & Bluetooth 5.3: With front-facing NFC secure element
- Up to 14-hour operating duration: 37.19 Wh Li-ion battery
The Pepperl+Fuchs Tab-IND 10 ThinManager Ready is a rugged Non-Ex industrial tablet designed for ThinManager-based digital workflows in industrial environments. This configuration combines a 10.1-inch display with an Intel N100 platform, 8 GB LPDDR5 RAM, 128 GB UFS storage and Wi-Fi 6 connectivity.
Unlike the Windows 11 and Android configurations in the Tab-IND range, this model is supplied with a ThinManager-ready BIOS rather than a conventional pre-installed operating system. It can boot firmware directly from ThinManager, enabling the tablet to operate as a centrally managed mobile endpoint within a Rockwell Automation ThinManager environment.
Within the 10.1-inch Tab-IND range, 480993-100012 is the dedicated ThinManager Ready configuration. Organisations requiring a conventional Windows 11 LTSC tablet can instead select the corresponding Tab-IND 10 WIN models, while this version is specifically intended for deployments built around centrally managed ThinManager infrastructure.
The tablet is suited to mobile industrial workflows across manufacturing, logistics and field service. Its WUXGA touchscreen supports passive stylus and cotton-glove operation, including improved use in wet and outdoor conditions, while the SmartBack interface and optional Scanner Frame support application-specific accessory integration.
For operational deployment, the Tab-IND 10 ThinManager Ready combines IP65 protection with an operating temperature range of -20 to +50 °C and a specified operating duration of up to 14 hours. Docking, charging, protection and handling accessories can be selected around the intended workflow and installation environment.
Key Features
- ThinManager Ready platform: The dedicated ThinManager configuration combines an Intel N100 quad-core processor with 8 GB LPDDR5 RAM and 128 GB UFS storage for ThinManager-based industrial deployments.
- Industrial touchscreen operation: The 10.1-inch WUXGA display supports a passive stylus, cotton gloves and improved operation in wet and outdoor conditions.
- Rugged and adaptable protection: IP65 protection and standard drop resistance are complemented by optional Scanner Frame and Rugged Frame configurations, increasing specified drop resistance up to 1.5 m on plywood and 1.8 m on concrete respectively.
- Industrial wireless connectivity: Wi-Fi 6, Bluetooth 5.3 with Bluetooth Low Energy and a front-facing NFC secure element support connected industrial workflows.
- Flexible peripheral integration: USB-C, a dedicated docking connector and SmartBack interface provide options for display, docking and compatible industrial accessory integration.
- Extended operating range and runtime: Operation from -20 to +50 °C and a specified operating duration of up to 14 hours support deployment across a broad range of industrial conditions.
- Imaging and expandable storage: 13 MP front and main cameras support visual and communication workflows, while the user-accessible microSDXC slot provides additional local storage where required.
Specifications
| System and Software | |
| Operating System | ThinManager Ready |
| Processor | Intel N100, quad-core, 2.9 GHz |
| RAM | 8 GB LPDDR5 |
| Internal Storage | 128 GB UFS |
| Expandable Storage | microSDXC card slot, accessible by end user |
| Display and Operation | |
| Touchscreen | Multi-touch |
| Screen Size | 10.1″ |
| Aspect Ratio | 16:10 |
| Resolution | 1920 × 1200 WUXGA |
| Brightness | 660 cd/m² |
| Stylus Support | Passive stylus, 4 mm tip |
| Glove Support | Cotton gloves |
| Wet-Use Support | Improved usage in wet environments, including rain and outdoor use |
| Camera and Sensors | |
| Front Camera | 13 MP |
| Main Camera | 13 MP |
| Sensors | E-compass, accelerometer, gyro, ambient light sensor, proximity sensor |
| Connectivity and Interfaces | |
| WLAN / Wi-Fi | IEEE 802.11 ac+r/k/v, Wi-Fi 6, WiDi |
| Bluetooth | Bluetooth 5.3, Bluetooth Low Energy |
| NFC | Front-facing NFC secure element |
| USB-C | USB 3.1 Gen 1, PD 12 V / 3 A, DisplayPort 1.2 |
| Docking Connector | USB 3.1 Gen 1, HDMI 1.4b |
| Accessory Interface | SmartBack connector |
| Power | |
| Battery | Li-ion, 37.19 Wh, 7.7 V, 4830 mAh |
| Operating Duration | Up to 14 h |
| USB-C Charging Requirement | PS2 (LPS)-compliant wall charger, minimum 27 W, conforming to USB-C standard |
| Environmental and Mechanical | |
| Operating Temperature | -20 to +50 °C |
| Storage Temperature | -20 to +60 °C |
| Relative Humidity | 10% to 90% |
| Degree of Protection | IP65 |
| Drop Resistance | 1 m onto concrete; 1.22 m onto plywood |
| With Optional Scanner Frame | Up to 1.5 m onto plywood |
| With Optional Rugged Frame | Up to 1.8 m onto concrete |
| Mass | Approx. 817 g |
| Dimensions (H × W × D) | 180.66 × 269.04 × 12.7 mm |
| International Approvals | |
| Approved Regions | EU (UK), US, CA, AU, JP, MX |
| Ordering | |
| Part Number | TAB-IND10WINAB1NBXXJW.1 |
| SAP Number | 480993-100012 |
Support
Able Instruments are an Official UK Technical Partner for Pepperl+Fuchs Enterprise Mobility, providing application advice, configuration support and lifecycle assistance for industrial mobile device deployments.
- Application guidance: Support confirming whether the Tab-IND is suitable for the intended environment, application and operational requirements
- Model selection: Guidance when comparing Tab-IND screen sizes, operating systems, memory, storage and connectivity options
- Technical support: Pre-sales advice and post-deployment assistance from UK-based specialists
- Device and accessory configuration: Assistance with setup and selection of compatible scanning, protection, docking, charging and handling accessories
Other Tab-IND Options
Accessories
- 570025 Scanner Frame 10″
- 70177206 Rugged Frame for Tab-IND 10
- 70177191 Full Docking Station (without Scanner Frame)
- 70177193 Full Docking Station (with Scanner Frame)
- 70177196 1-Bay Desktop Charging Station
- 70177209 Adjustable Nylon Hand Strap
