CENEGEX DCx13-3 Zone 2/22 ATEX Digital Camera
Zone 2/22 ATEX digital camera with intrinsically secure wired USB data transfer for controlled image capture in restricted hazardous-area environments.
Key highlights
- Zone 2/22: ATEX certified for hazardous gas and dust environments
- USB datalink: Charging, image and data transfer via intrinsically secure wired connection
- No-wireless workflow: Suitable where WiFi or Bluetooth transfer is not appropriate
- 13MP capture: Still image and movie capture for controlled site documentation
- 64GB memory: Onboard storage for controlled image handling
The CENEGEX DCx13-3 is an ATEX certified digital camera for still image and movie capture in Zone 2 gas and Zone 22 dust hazardous areas. It is designed for industrial users who need a portable camera for controlled photographic documentation in classified environments.
Within Able’s hazardous-area camera range, the DCx13-3 is best suited to users who need a controlled-data camera workflow rather than a smartphone-style inspection device or an optical zoom / macro camera. Its role is focused on restricted-site image capture, wired USB transfer and controlled handling of inspection records.
The camera includes a 13MP sensor with motorised focus, 64GB onboard memory, digital zoom, movie capture and a close-up flash feature for low-light image capture. A 4.6″ touchscreen and traditional push-button controls support operation in harsh conditions, including image capture when gloves are required.
The defining feature of the DCx13-3 is its intrinsically secure wired USB datalink, which is used for charging, image download and data transfer. This makes it particularly relevant where WiFi or Bluetooth workflows are not appropriate, such as security-conscious industrial sites or facilities with strict data-transfer rules.
The DCx13-3 also supports legacy CorDEX and iCorDEX enquiries, where users may still search using previous manufacturer or product naming. For these requirements, the current CENEGEX DCx13-3 provides a Zone 2/22 hazardous-area camera route with controlled data handling and current product supply support.
Key Features
- Zone 2/22 hazardous-area use: Supports still image and movie capture in relevant gas and dust classified environments
- Controlled data workflow: Provides a camera option for sites where WiFi or Bluetooth image transfer is not appropriate
- Intrinsically secure USB datalink: Enables charging, image download and data transfer through a wired connection
- 13MP image capture: Uses automatic and manually directed motorised focus to support clear photographic documentation
- 64GB onboard memory: Provides internal storage for controlled handling of captured images and data
- Touchscreen and push-button operation: Allows camera settings and image capture to be managed in harsh conditions, including gloved use
- Close-up flash feature: Supports image capture in low-light or close-range documentation tasks
- Legacy camera continuity: Relevant for users looking for current CENEGEX supply, CorDEX replacement or iCorDEX upgrade enquiries
Specifications
| Certification and Protection | |
| Product Type | ATEX Zone 2/22 Digital Camera |
| ATEX Marking | II 3 G Ex nR IIC T6 Gc and II 3 D Ex tc IIIC T85°C Dc |
| Ingress Protection | IP54 |
| Mechanical | |
| Casing | Aluminium casing |
| Drop Protection | Drop resistant boot |
| Dimensions | 160 mm x 97 mm x 30 mm, excluding lens turret |
| Weight | 650 g / 1.4 lb |
| Lanyard Points | Yes, twin |
| Imaging | |
| Image Sensor | 13MP sensor with automatic and manually directed motorised focus |
| Still Image Resolution | 13MP, 12MP, 8MP, 4MP, 3MP, 2MP, 1MP |
| Movie Resolution | HD1080P, HD720P |
| Zoom | x8 digital |
| Flash | Close-up flash |
| ISO Adjustment | AUTO, 100, 200, 400, 800, 1600 |
| White Balance | Yes |
| Exposure | Yes |
| Countdown Timer | Off, 2s, 5s, 10s |
| Display and Operation | |
| Touchscreen | 4.6″ / 116 mm touchscreen |
| Operating Modes | Touchscreen operation and traditional push-button operation |
| Gloved Use | Parallel operating modes allow image capture with gloves and in harsh conditions |
| Power, Memory and Data | |
| Battery | 3.7V Lithium Ion, 2000mAh |
| Onboard Memory | 64GB high-speed onboard memory |
| Data and Charging | Intrinsically Secure USB Datalink |
Scope of Delivery
- DCx13-3 ATEX Certified Digital Camera
- Transport pouch
- Intrinsically Secure Datalink Cable
- Wrist strap
- Manuals
Support
Able Instruments are an authorised representative for CENEGEX, providing selection support, technical guidance and supply assistance for controlled-data hazardous-area camera requirements.
- Application guidance: Support with confirming whether the DCx13-3 is suitable for Zone 2/22 image capture, restricted-site use or controlled data handling
- Range comparison: Guidance when comparing CENEGEX against smartphone-style ATEX cameras or optical zoom / macro camera options
- Legacy camera support: Assistance with CorDEX and iCorDEX replacement, upgrade and procurement enquiries
- Supply support: Help with pricing, lead time, project supply and formal quotation requirements
